Product Features

1. All clamps are made of high-strength structural steel, which greatly improves the strength of the head and prolongs the overhaul cycle of the head.

2. Three-phase input, high power factor (compared to single-phase), high efficiency of heat input, relatively low power consumption.

3. System dynamic response speed, stable output, stable welding quality.

Main Technical Parameters

Generator power: 350KVA

Rated upsetting force: 1200KN

Maximum clamping force: 3000KN

Maximum weldable rail area: 10000mm²

Maximum welding stroke: 150mm

Rated pressure of hydraulic system: 21MPa

Total weight: 24t
